Description
75%
Energy Savings
95%
Maintenance Savings
Colour Temperature | Warm, Daylight, Natural |
---|---|
Wattage | 20W, 40W, 50W |
Dimmable | Yes (0-10V, DALI optional) |
Operating Temp | -20°C to 50°C |
Beam Angle | 120° |
Lumens per Watt | 110Lm/W |
CRI | >80Ra |
IP Rating | IP65 |
Impact Protection | IK08 |
Protection Class | Class I |
Lifespan | 50,000 Hours |
Finish | Silver |
Size | 4ft & 5ft (see detailed dimensions below) |
Materials | PVC & PC lens (shatterproof) |
Wireless Lighting Control | Yes – Compatible with Light Boss |
G5 LED Linear Batten Description
The Goodlight™ G5 multi-functional linear LED Batten luminaire is designed to replace standard fluorescent fixtures in interior and exterior applications, housed in a sleek body, and IP65-protected with a high-density silicon rubber seal, making it waterproof (IP65), dust proof and anti-corrosive (weather-proof).The fitting is totally glass-free, featuring a shatterproof PC lens providing uniform light which transmits over 95% light efficacy, making it additionally suitable for food and drink production environments.
The G5 delivers up to 110 lumens per watt of brightness, utilising SMD2835 LEDs, with a 120° beam angle for optimal light spread. Variants include a standard model in 4ft and 5ft lengths. The G5 can be recessed, suspended or surface-mounted. Supplied with stainless steel mounting clips, as standard, for an easy and simple installation (surface-mounted).
G5 LED Linear Batten + Wireless Lighting Control
The Goodlight™ G5 LED Batten is compatible with Light Boss™ Wireless Lighting Control. Light Boss™ puts an intuitive lighting system at the heart of your building’s operation. Automate your lighting triggered by occupancy, daylight or user preference. Light Boss™ dims down your lighting when no one is around, or when it detects natural light, and turns back on again when it is needed, for the ultimate energy efficient lighting control. Suitable for new builds and retrofits. Light Boss™ provides ‘live’ reporting on the energy consumption of all connected lighting fixtures, allowing energy management via a single dashboard – an ideal tool for complete energy performance of single or multi-site estates. Operate your lighting where it is needed, rather than at 100% continually, allowing you to minimise energy consumption by up to 95%, extend lighting lifecycles and lower maintenance costs. Payback from as little as 1.5 years. Other features include; Energy Monitoring, Emergency Light Testing, Daylight Monitoring, Service Plus, LED Fault Monitoring, Group and Scene Setting and Circadian Lighting. Suitable for offices, warehouses, retail, leisure, car parks, education, healthcare, amenity, logistics and transportation.
To integrate Light Boss™, simply choose your G5 LED Batten(s) from the options above and select ‘Yes’ next to ‘Wireless Lighting Control’ to submit your quote request.
G5 LED Linear Batten Features
- Available in Daylight (5.8K – 6.1K), Natural (4K – 4.2K), Warm (3K – 3.1K)
- Replaces standard, twin fluorescent fixtures
- Multi-Protection: Dust Proof, Corrosion Proof & Water Proof (IP65)
- Suitable for commercial and industrial environments
- Available in 4ft & 5ft lengths
G5 LED Linear Batten Applications
- Industrial
- Retail
- Car Parks
- Amenity Lighting
- Offices & Commercial
- Cold Storage & Refrigeration
- Food & Drink Production
- Healthcare
Additional information
Lumens per Watt | 110Lm/W |
---|
